Led headlight HD-Style 7"

7-inch HD-STYLE TYPE 2 LED headlight, metal housing, round, bottom-mounted, E-approved. Available in various colors.

LED headlight HIGHSIDER 7 inch HD-STYLE TYPE 2 for bottom mounting

Elegant, innovative Power LED headlight in purist design with position light function and round glass transparent. The oval housing in satin-finish black or chrome-plated metal features a black or chrome-plated asymmetrical insert - legal for right-hand traffic only - marked E.

Pure joie - give your bike an unmistakable style! The unusual design and perfect technology of the HIGHSIDER headlamp series make it a point highlight in every case!

Dimensions:
Housing diameter: 220 mm
Headlight insert diameter: 178 mm
Depth: 155 mm
Distance between mounting holes on bracket (middle - middle): 65 mm

Power consumption at 12.5 volts DC:
Low beam: approx. 1.6 amps (20 watts), 12 volts 1450 lumens
Only the top reflector and central ellipsoidal insert are lit.
High beam: approx. 1.6 amps (20 watts), 12 volts, 1582 lumens
Only the top and bottom reflectors are lit. The central ellipsoidal insert also goes out when the headlights are flashing.

Connections on the reflector in the headlamp housing
The following 3 cables are terminated by a combination plug:
black cable = ground (-)
red cable = high beam (+)
blue cable = low beam (+)
2 additional cables for position lights:
black = ground (-),
red = position light (+)
white = connection for control screen (can be used as an option)

Scope of delivery: 1 piece with counter-connector (plug) with 210 mm cable, for H4 halogen bulbs, connections:
green cable = ground (-)
blue cable = high beam (+)
white cable = low beam (+)

Notes:
Asymmetrical use, approved for right-hand traffic only.
